Product Summary

The IRFI730GPBF is a HEXFET Power MOSFET. The IRFI730GPBF from International Rectifier provide the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-220 Fullpak eliminates the need for additional insulating hardware in commercial-industrial applications. The moulding compound used provides a high isolation capability and a low thermal resistance between the tab and external heatsink. This isolation is equivalent to using a 100 micron mica barrier with standard T0-220 product. The IRFI730GPBF is mounted to a heatsink using a single clip or by a single screw fixing.


Parametrics

IRFI730GPBF absolute maximum ratings: (1) Tc=25℃ Continuous Drain Current, Vgs @ 10 V: 3.7A; (2)lD@ Tc= 100℃ Continuous Drain Current, Vgs @ 10 V: 2.3 A; (3)I DM Pulsed Drain Current: 15A; (4)Pd @ Tc = 25℃ Power Dissipation: 35W; (5)Vgs Gate-to-Source Voltage: ±20 V; (6)Eas Single Pulse Avalanche Energy: 200mJ; (7)Iah Avalanche Current: 3.7A; (8)Ear Repetitive Avalanche Energy: 3.5mJ; (9)dv/dt Peak Diode Recovery dv/dt: 4.0V/ns; (10)Tj Operating Junction: -55 to +150℃.

Features

IRFI730GPBF features: (1)Floating channel designed for bootstrap operation Fully operational to +600V Tolerant to negative transient voltage dV/dt immune; (2)Gate drive supply range from 10 to 20V; (3)Undervoltage lockout; (4)3.3V, 5V and 15V input logic compatible; (5)Cross-conduction prevention logic; (6)Internally set deadtime; (7)High side output in phase with input; (8)Shut down input turns off both channels; (9)Matched propagation delay for both channels; (10)Also available LEAD-FREE.

Diagrams

IRFI730GPBF pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRFI730GPBF
IRFI730GPBF

Vishay/Siliconix

MOSFET N-Chan 400V 3.7 Amp

Data Sheet

0-1: $1.34
1-10: $1.17
10-100: $1.00
100-250: $0.75
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRFI1010N
IRFI1010N

International Rectifier

MOSFET N-CH 55V 49A TO220FP

Data Sheet

1-150: $7.73
IRFI1010NPBF
IRFI1010NPBF

International Rectifier

MOSFET MOSFT 55V 44A 12mOhm 86.7nC

Data Sheet

0-1: $1.18
1-25: $0.76
25-100: $0.55
100-250: $0.52
IRFI1310G
IRFI1310G

Other


Data Sheet

Negotiable
IRFI1310N
IRFI1310N


MOSFET N-CH 100V 24A TO220FP

Data Sheet

Negotiable
IRFI1310NPBF
IRFI1310NPBF

International Rectifier

MOSFET MOSFT 100V 22A 36mOhm 80nC

Data Sheet

0-1: $1.16
1-25: $0.75
25-100: $0.54
100-250: $0.51
IRFI260
IRFI260

Other


Data Sheet

Negotiable
