Product Summary
The FMS6400CS1X is a dual channel video driver with integrated filters and composite video summer. The FMS6400CS1X is optimized for minimum overshoot and flat group delay. The FMS6400CS1X also contains a summing circuit to generate filtered composite video. In a typical application, the Y and C input signals from DACs are AC coupled into the filters. Both channels have DC restore circuitry to clamp the DC input levels during video sync. The Y and C channels use separate feedback clamps. The clamp pulse is derived from the Y channel.
Parametrics
FMS6400CS1X absolute maximum ratings: (1)DC Supply Voltage: -0.3 to 6 V; (2)Analog and Digital I/O: -0.3 to Vcc + 0.3 V; (3)Output Current Any One Channel, Do Not Exceed: 40 mA; (4)Junction Temperature: 150 ℃; (5)Storage Temperature Range: -65 150 ℃; (6)Lead Temperature (Soldering, 10s): 300 ℃; (7)Thermal Resistance (ThetaJA), JEDEC Standard Multi-Layer Test Boards, Still Air: 115 ℃/W; (8)Operating Temperature Range: 0 to 70 ℃; (9)Supply Voltage Range 4.75 to 5.25 V.
Features
FMS6400CS1X features: (1)5.0 MHz 5th order Y,C filters with composite summer; (2)Selectable for 0dB or 6dB gain; (3)50dB stopband attenuation at 27MHz on Y, C and CV outputs; (4)No external frequency selection components or clocks; (5)AC-Coupled Inputs; (6)AC or DC-Coupled Outputs; (7)Continuous time low pass filters; (8)0.4% / 0.4 differential gain/phase on Y,C and CV channels; (9)Integrated DC restore circuitry with low tilt; (10)Lead (Pb)Free SOIC-8 Package.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 FMS6400CS1X |
Fairchild Semiconductor |
Video ICs Dual Channel VidDrvr |
Data Sheet |
Negotiable |
|
||||||||||||
