Product Summary
The TLP2200(F) is a high speed line receiver. The TTLP2200(F) consists of a light emitting diode and integrated high gain, high speed photodetector. The TLP2200(F) is 8 lead DIP package. The detector has a three state output stage that eliminates the need for pull up resistor, and built in schmitt trigger. The TLP2200(F) has an internal shield that provides a guaranteed common mode transient immunity of 1000V / μs.
Parametrics
TLP2200(F) absolute maximum ratings: (1)Forward current IF: 10 mA; (2)Peak transient forward current (Note 1)IFPT: 1 A; (3)Reverse voltage VR: 5 V; (4)Output current IO: 25 mA; (5)Supply voltage VCC: -0.5~20 V; (6)Output voltage VO: -0.5~20 V; (7)Three state enable voltage VE: -0.5~20 V; (8)Total package power dissipation PT: 210 mW; (9)Operating temperature range Topr: -40~85 ℃; (10)Storage temperature range Tstg: -55~125 ℃; (11)Lead solder temperature (10s) Tsol: 260 ℃; (12)Isolation voltage (AC 1min., R.H. ≤ 60%,Ta = 25℃)BVS:2500 Vrms.
Features
TLP2200(F) features: (1)Input current: IF = 1.6mA; (2)Power supply voltage: VCC = 4.5~20V; (3)Switching speed: 2.5MBd guaranteed; (4)Common mode transient immunity: ±1000V / μs (min.); (5)Guaranteed performance over temp: 0~85℃; (6)Isolation voltage: 2500Vrms(min.); (7)UL recognized: UL1577, file No. E67349.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLP2200(F) |
|
PHOTOCOUPLER LOGIC OUT 8-DIP |
Data Sheet |
|
|
||||||||||||||||||||||
