Product Summary
The IM01GR is an IM relay. Applications of the IM01GR include: Communications equipment Linecard application-analog, ISDN, xDSL,PABX Voice over IP, Office and business equipment, Measurement and control equipment, Consumer electronics Set top boxes, HiFi and Medical equipment.
Parametrics
IM01GR absolute maximum ratings: (1) Limiting continuous current at max. ambient temperature: 2A; (2) Maximum switching current: 2A; (3) Maximum swichting voltage: 220Vdc, 250Vdc; (4) Maximum switching capacity: 60W, 62.5VA.
Features
IM01GR features: (1) Telecom/signal relay (dry circuit, test access, ringing) ; (2) Low profile 5.65 mm, 0.222 inch; (3) Switching current 2A; (4) Bifurcated contacts, gold plated; (5) High sensitivity results in low nominal power consumption; (6) High surge capability (1.2/50 PAs and 10/700μs) meets Bellcore GR 1089, FCC Part 68 and ITU-T K20 ≥1500V between open contacts, ≥2500V between coil and contacts; (7) High mechanical shock resistance.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 IM01GR |
TE Connectivity / Axicom |
High Frequency / RF Relays 140 mW 3 V 10 |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
 |
IM01BH2R2K |
Vishay/Dale |
Power Inductors 2.2uH 10% |
Data Sheet |
|
|
||||||||||||
 |
IM01CGR |
TE Connectivity / Axicom |
High Frequency / RF Relays 140MW 3V 8 |
Data Sheet |
|
|
||||||||||||
|
IM01GR |
TE Connectivity / Axicom |
High Frequency / RF Relays 140 mW 3 V 10 |
Data Sheet |
|
|
||||||||||||
|
IM01TS |
TE Connectivity / Axicom |
High Frequency / RF Relays 140 MW 3 V 10 |
Data Sheet |
|
|
||||||||||||
|
IM01NS |
TE Connectivity / Axicom |
High Frequency / RF Relays 140 MW 3 V 10 |
Data Sheet |
|
|
||||||||||||
|
IM01JR |
TE Connectivity / Axicom |
High Frequency / RF Relays 140 MW 3 V 10 |
Data Sheet |
|
|
||||||||||||
