Product Summary

The OPA2350EA/2K5G4 is a rail-to-rail CMOS operational amplifier. The OPA2350EA/2K5G4 is optimized for low voltage, single-supply operation. Rail-to-rail input/output, low noise (5nV/√Hz), and high speed operation (38MHz, 22V/μs) make them ideal for driving sampling Analog-to-Digital (A/D) converters. The OPA2350EA/2K5G4 is also well suited for cell phone PA control loops and video processing (75Ω drive capability) as well as audio and general purpose applications. Single, dual, and quad versions have identical specifications for maximum design flexibility.

Parametrics

OPA2350EA/2K5G4 absolute maximum ratings: (1)Supply Voltage: 7.0V; (2)Signal Input Terminals, Voltage: -0.3V to (V+)+ 0.3V, Current: 10mA; (3)Open Short-Circuit Current: Continuous; (4)Operating Temperature Range: -55℃ to +150℃; (5)Storage Temperature Range: -55℃ to +150℃; (6)Junction Temperature: +150℃; (7)Lead Temperature (soldering, 10s): +300℃.:

Features

OPA2350EA/2K5G4 features: (1)rail-to-rail input; (2)rail-to-rail output (within 10mv); (3)wide bandwidth: 38mhz; (4)high slew rate: 22V/μs; (5)low noise: 5nV/√Hz; (6)low thd+noise: 0.0006%; (7)unity-gain stable; (8)microsize packages; (9)single, dual, and quad.

Diagrams

OPA2350EA/2K5G4 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
OPA2350EA/2K5G4
OPA2350EA/2K5G4

Texas Instruments

High Speed Operational Amplifiers Hi-Spd Single-Sply Rail-to-Rail

Data Sheet

0-1855: $1.30
1855-2000: $1.22
2000-2500: $1.22
2500-5000: $1.20
