Product Summary

The PC3H4J00000F is a Mini-falt Package AC Input Type Half Pitch Photocoupler. The applications of the PC3H4J00000F include Programmable controllers.

Parametrics

PC3H4J00000F absolute maximum ratings: (1)Forward current, IF: ±50mA; (2)Power dissipation, IFM: ±1A; (3)Collector power dissipation, P: 70mW; (4)Collector-emitter voltage, VCEO: 70V; (5)Emitter-collector voltage, VECO: 6V; (6)Colletor current, IC: 50mA; (7)Collector power dissipation, Pc: 150mW; (8)Total power dissipation, Ptot: 170mW; (9)Isolation voltage, Viso: 2.5KVrms; (10)Operating temperature, Topr: -30 to +100℃; (11)Storage temperature, Tstg: -40 to +125℃; (12)Soldering temperature, Tsol: 260℃.

Features

PC3H4J00000F features: (1)AC input type; (2)Half pitch type (lead pitch : 1.27mm); (3)Isolation voltage between input and output (Viso: 2 500Vrms); (4)Applicable to infrared ray reflow (230℃, for MAX. 30s); (5)High reliability; (6)Taping package PC3H4 (1ch), PC3Q64Q (4ch); (7)Recognized by UL, file No. E64380 Approved by VDE, No.5922UG.
