Product Summary

TheUPA1600GS-E2-A is a Monolithic N-channel Power MOS FET Array that built in 8 circuits and Gate Protection Diode designed for LED, Relay, Thermal Head, and so on.

Parametrics

UPA1600GS-E2-A absolute maximum ratings: (1)Output Voltage Vo: 30 V; (2)Input Voltage Vi: -0.5 to +10 V; (3)Output Current lo: 500 mA; (4)Input Current li: ±10 mA; (5)GND Terminal Current: 2.0 A; (6)Total Power Dissipation Pt: 1.0 W; (7)Operating Temperature Topt: -40 to +85 ℃; (8)Storage Temperature Tstg: -55 to+150 ℃.

Features

UPA1600GS-E2-A features: (1)Direct driving is possible by standard Logic IC or Microcomputer. (4 V driving is possible); (2)Output Voltage: Vo = 30 V MAX. Output Current: lo = 500 mA MAX.; (3)Ron = 3 a at: lo = 200 mA, Vi = 4 V; (4)Gate Protection Diode, built in.


Diagrams

UPA1600GS-E2-A pin connection
