Product Summary
The AAT1109-S-T is a one-channel step-up PWM controller incorporating a soft-start and a short circuit protection (SCP) function. The AAT1109-S-T consists of an on-chip voltage reference, error amplifier, pulse width modulation controller, under-voltage lockout protection, soft-start, and short circuit protectiocircuits. Switching frequency up to 1MHz is set by an external resistor and capacitor. Soft-start time can be implementedby the SCP capacitor.
Parametrics
AAT1109-S-T absolute maximum ratings: (1)Supply Voltage, VDD: 7V; (2)Output Current, IO: -120/+120mA; (3)Operating Free-Air Temperature Range, TC: -20 to +85℃; (4)Storage Temperature Range, Tstorage: -45℃ to +125℃; (5)Power Dissipation, Pd: 500mW.
Features
AAT1109-S-T features: (1)Under-Voltage Lockout (UVLO) Protection; (2)Totem Pole Output; (3)Output Short Circuit Protection; (4)Soft-Start Function; (5)Wide Operating Frequency：10 kHz to 1MHz; (6)Shutdown Control; (7)Low Dissipation Current: Typical 1.6mA in Operation; (8)SOP-8 & TSSOP-8 Package Available.
