DS90CF363BMTX/NOPB

3V programmable LVDS transmitter, 4V, 1.98 W, 68 MHz, 48-TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.60~1.76 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.60~1.76

PartNumber:: DS90CF363BMTX/NOPB

Brand:: National Semiconductor - NS | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Melody's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-22

From Other Seller

Part Number:DS90CF363BMTX/NOPB
US $1.60 - 1.76
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
IRF9540NPBF

US $0.50 - 3.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DS90CF363BMTX/NOPB is a 3V programmable LVDS transmitter. The DS90CF363BMTX/NOPB transmitter converts 21 bits of CMOS/TTL data into three LVDS (Low Voltage Differential Signaling) data streams. A phase-locked transmit clock is transmitted in parallel with the data streams over a fourth LVDS link. Every cycle of the transmit clock 21 bits of input data are sampled and transmitted. At a transmit clock frequency of 65 MHz, 18 bits of RGB data and 3 bits of LCD timing and control data (FPLINE, FPFRAME, DRDY) are transmitted at a rate of 455 Mbps per LVDS data channel. Using a 65 MHz clock, the data throughput is 170 Mbytes/sec. The DS90CF363BMTX/NOPB is fixed as a Falling edge strobe transmitter and will interoperate with a Falling edge strobe Receiver (DS90CF366) without any translation logic.

Parametrics

DS90CF363BMTX/NOPB absolute maximum ratings: (1)Supply Voltage (VCC): -0.3V to +4V; (2)CMOS/TTL Input Voltage: -0.3V to (VCC + 0.3V); (3)LVDS Driver Output Voltage: -0.3V to (VCC + 0.3V); (4)LVDS Output Short Circuit Duration Continuous Junction Temperature: +150℃; (5)Storage Temperature: -65℃ to +150℃; (6)Lead Temperature (Soldering, 4 sec): +260℃; (7)Maximum Package Power Dissipation Capacity @ 25℃ MTD48 (TSSOP)Package: DS90CF363B: 1.98 W.
