Product Summary

The DTDG14GPT100 is a digital transistor (built in resistor and zener diode) driver.

Parametrics

DTDG14GPT100 absolute maximum ratings: (1)Collector-base voltage: 60±10V; (2)Collector-emitter voltage: 60±10V; (3)Collector current: 2A; (4)Collector power dissipation: 2W; (5)Junction temperature: 150°C; (6)Emitter-base voltage: 5V; (7)Storage temperature: -55~+150°C.

Features

DTDG14GPT100 features: (1)Up To 85% Efficiency; (2)Thermal Protection; (3)Device-to-Device Synchronization; (4)Short-Circuit Protection; (5)EN55022 Class B EMC Performance; (6)UL1950 Recognized Component; (7)JEDEC DIP-14 and SOP-14 Packages.

Diagrams

DTDG14GPT100 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
DTDG14GPT100
DTDG14GPT100

ROHM Semiconductor

Transistors Switching (Resistor Biased) DIGITAL NPN 60V 1A

Data Sheet

0-1: $0.28
1-25: $0.22
25-100: $0.16
100-500: $0.10
500-1000: $0.09
