Product Summary
The FH23-45S-0.3SHW(05) is a 0.3mm contact pitch, 1,25mm above the board, flexible printed circuit connector. Applications of the FH23-45S-0.3SHW(05) include: Mobile phones, digital cameras, digital video cameras and other compact devices requiring interconnections of the main circuit with the LCD, plasma display (PDP) , camera module, or other devices.
Parametrics
FH23-45S-0.3SHW(05) absolute maximum ratings: (1) Current rating: 0.3A DC; (2) Voltage rating: 30V AC; (3) Operating temperature range: -55 to +85°C; (4) Storage)temperature) range: -10 to +50°C; (5) Operating humidity range Relative humidity 90% max.; (6) Storage)humidity)range Relative) humidity 90% max.
Features
FH23-45S-0.3SHW(05) features: (1) FPC low insertion force and high holding force; (2) Temporary hold of FPC; (3) Easy board mounting; (4) Proven Flip-lock Actuator assures easy and reliable operation ; (5) Variations to suit different mounting areas ; (6) Designed for placement with automatic equipment; (7) Accepts 0.2mm thick FPC; (8) Variety of contact positions.
Diagrams
