Product Summary
The SK75TAE12 is a thyristor and diode separated in the same housing.
Parametrics
SK75TAE12 absolute maximum ratings: (1)It Ts=80℃: 75 A; (2)It Ts=100℃: 50 A; (3)Itsm Tvj = 130 ℃; 10 ms: 1250 A; (4)l2t TVj = 130 ℃; half sine wave, 10 ms: 7810 A2s; (5)Tstg: -40 : +130℃; (6)Tsolder terminals, 10 s: 260℃.
Features
SK75TAE12 features: (1)Compact Design; (2)One screw mounting; (3)Heat transfer and isolation through direct copper bonded aluminium oxide ceramic (DBC); (4)Glass passivated thyristor chips; (5)Up to 1600V reverse voltage.
Diagrams
