Product Summary

The TD62387AFG is an 8 Ch Low Input Active Darlington Sink Driver, which comprised of eight NPN darlington output stages and PNP input stages. The unit features integral clamp diodes for switching inductive loads. The TD62387AFG is Low Level input active driver and is suitable for operations with TTL, 5 V CMOS and 5 V Microprocessor which has sink current output drivers. Applications include relay, hammer, lamp and LED driver.

Parametrics

TD62387AFG absolute maximum ratings: (1)Supply Voltage VCC: -0.5 to 7.0 V; (2)Output Sustaining Voltage VCE (SUS): -0.5 to 50 V; (3)Output Current, IOUT: 500 mA/ch; (4)Input Voltage, VIN1: -22 to VCC +0.5V; VIN2: -0.5 to 7 V; (5)Input Current IIN: -10 mA; (6)Clamp Diode Reverse Voltage, VR: 50 V; (7)Clamp Diode Forward Current, IF: 500 mA; (8)Power Dissipation, PD (Note 3), APG, 1.38W; AFG: 1.0W; (9)Operating Temperature, Topr: -40 to 85℃; (10)Storage Temperature, Tstg: -55 to 150℃.

Features

TD62387AFG features: (1)Output current (single output) 500 mA (Max); (2)High sustaining voltage 50 V (Min); (3)Output clamp diodes; (4)Low level active input; (5)Standard supply voltage; (6)Inputs compatible with TTL and 5 V CMOS; (7)Package type-APG: DIP-20 pin; (8)Package type-AFG: SOP-20 pin.
