Product Summary

The DS32KHZSN#T&R is a temperature-compensated crystal oscillator (TCXO) with an output frequency of 32.768kHz. The DS32KHZSN#T&R addresses applications requiring better timekeeping accuracy, and can be used to drive the X1 input of most Dallas Semiconductor real-time clocks (RTCs), chipsets, and other ICs containing RTCs. The DS32KHZSN#T&R is available in commercial (DS32kHz) and industrial (DS32kHz-N) temperature versions.

Parametrics

DS32KHZSN#T&R absolute maximum ratings: (1)Voltage Range on Any Pin Relative to Ground: -3.0V to +7.0V; (2)Operating Temperature Range (Noncondensing)Commercial: 0°C to +70°C; (3)Industrial: -40°C to +85°C; (4)Storage Temperature Range: -40°C to +85°C; (5)Soldering Temperature (BGA, SO): See the Handling, PC Board Layout, and Assembly section.; (6)Soldering Temperature, Leads (DIP): +260°C for 10 seconds.

Features

DS32KHZSN#T&R features: (1)Accurate to ±4 Minutes/Year (-40°C to +85°C); (2)Accurate to ±1 Minute/Year (0°C to +40°C); (3)Battery Backup for Continuous Timekeeping; (4)VBAT Operating Voltage: 2.7V to 5.5V with VCC; (5)Grounded; (6)VCC Operating Voltage: 4.5V to 5.5V; (7)Operating Temperature Range: 0°C to +70°C (Commercial), -40°C to +85°C (Industrial); (8)No Calibration Required; (9)Low-Power Consumption; (10)Surface Mountable Using BGA Package; (11)UL Recognized.

Diagrams

DS32KHZSN#T&R pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
DS32KHZSN#T&R
DS32KHZSN#T&R

Maxim Integrated Products

TCXO Oscillators 32.768Khz Temp Cntrld Crystal Osc

Data Sheet

0-745: $2.52
745-1000: $2.28
DS32KHZSN#T&R-W
DS32KHZSN#T&R-W

Maxim Integrated Products

TCXO Oscillators

Data Sheet

Negotiable
