Product Summary
The TC4S81F is a 2-input positive logic AND gate. Gate output with inverter buffer improve the input- output characteristics and even if the load capacitance increases, it can be stopped the change of propagation time.
Parametrics
TC4S81F absolute maximum ratings: (1)DC Supply Voltage VDD: V55 - 0.5~Vss + 20 V; (2)Input Voltage VIN: V55 - 0.5~VDD+ 0.5 V; (3)Output Voltage vOUT: V55 - 0.5~Vqd + 0.5 V; (4)DC Input Current Iin: ± 10 mA; (5)Power Dissipation Pd: 200 mW; (6)Operating Temperature Range Topr: -40-85 ℃; (7)Storage Temperature Range Tstg: - 65- 150 ℃; (8)Lead Temperature (10s)tl: 260 ℃.
Features
TC4S81F features: (1)DC Supply Voltage Vqq: 3 to 18 V; (2)Input Voltage VIN: 0 to VDD V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TC4S81F |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
TC4S81F(T5L,F,T) |
Toshiba |
Gates (AND / NAND / OR / NOR) 2-Input AND Gate 5Pin Standard |
Data Sheet |
Negotiable |
|
||||||
|
TC4S81F(TE85L,F) |
|
IC GATE AND 2INPUT POS SSOP5 |
Data Sheet |
|
|
||||||
