ZXTP2012ZTA

ZXTP2012ZTA, PNP low saturation medium power transistor, SOT, -60V, -4.3A, Zetex Semiconductors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.22 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~0.22

PartNumber:: ZXTP2012ZTA

Brand:: Zetex Semiconductors - Zetex | Pack: SOT | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Melody's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-18

From Other Seller

Part Number:ZXTP2012ZTA
US $0.20 - 0.22
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ZXTP2012ZTA is a PNP low saturation medium power transistor. Packaged in the SOT89 outline this new low saturation 60V PNP transistor offers low on state losses making it ideal for use in DC-DC circuits, line switching and various driving and power management functions. The applications of the ZXTP2012ZTA include Emergency lighting circuits, Motor driving (including DC fans), Solenoid, relay and actuator drivers, DC-DC modules, Backlight inverters, Power switches, MOSFET gate drivers.

Parametrics

ZXTP2012ZTA absolute maximum ratings: (1)Collector-base voltage, BVCBO: -100 V; (2)Collector-emitter voltage, BVCEO: -60 V; (3)Emitter-base voltage, BVEBO: -7 V; (4)Continuous collector current, IC: -4.3 A; (5)Peak pulse current, ICM: -15 A; (6)Power dissipation at TA =25℃, PD: 1.5W; Linear derating factor, PD: 12mW/℃; (7)Operating and storage temperature range, Tj, Tstg: -55 to +150℃.

Features

ZXTP2012ZTA features: (1)Extremely low equivalent on-resistance; RSAT = 32mV at 5A; (2)4.3 amps continuous current; (3)Up to 15 amps peak current; (4)Very low saturation voltages; (5)Excellent gain characteristics specified up to 10 amps.
